PWM Controlled LED Endoscopy Light Source

Get a Price/Quote

PWM Controlled LED Endoscopy Light Source Specification

Dimension (L*W*H)
260 x 210 x 110 mm

Height
110 mm

Phase
Single Phase

Suitable For
All Rigid and Flexible Endoscopes

Shape
Rectangular

Display Type
LED Digital

Weight
2.5 kg

Humidity Range
Up to 90% RH (Non-condensing)

Material
Metal Body with Polycarbonate Panel

Color Code
White and Blue

Product Type
LED Endoscopy Light Source

Treatment Type
Endoscopy

Use
Provides high output illumination for endoscopic visualization

Application
Endoscopic Examination and Surgical Procedures

Function
PWM Controlled Illumination

Temperature Range
10C to 40C (Operating)

Frequency
50 Hz

Accuracy
High Optical Output Stability

Automation Grade
Automatic

Properties
High Intensity, PWM Brightness Control, Long Life LED, Low Heat Emission

Power
40W

Power Source
Electric (AC) Powered

Voltage
220V AC

Display
Digital Brightness Display

Connector Type
Universal Endoscope Light Guide Adapter

Light Source Type
High Power White LED

Startup Time
Instant On (< 1 second)

Noise Level
< 30 dB

LED Life Span
Approx. 50,000 Hours

Color Temperature
6000 - 6500K

Protection
Overload, Over Voltage, Over Temperature

Cooling Type
Silent Forced Air Cooling

Brightness Adjustment
0-100% (stepless, via PWM slider or digital control)

Luminous Flux
> 2200 Lumens

PWM Controlled LED Endoscopy Light Source Trade Information

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About PWM Controlled LED Endoscopy Light Source

PWM Controlled LED Endoscopy Light Source that we provide is a real-time endoscopic light source. It makes the use of light emitting diode technology to emit light. It helps reducing ownership cost and environmental waste. Due to its premium quality and ergonomic design, we are seeing a huge demand for the device in the marketplace. PWM Controlled LED Endoscopy Light Source is easy to install and operate. It can be purchased from us at a reasonable price.

Exemplary Illumination Performance

Powered by high-intensity white LEDs, this light source produces over 2200 lumens, delivering clear, consistent lighting for endoscopic visualization. Users benefit from a color temperature range of 60006500K, offering daylight-quality illumination to enhance tissue differentiation during procedures.

Adaptability and Ease of Use

Suitable for all rigid and flexible endoscopes, the system comes equipped with a universal light guide adapter and provides instant-on operation for urgent clinical needs. The stepless PWM-controlled brightness ensures exact control tailored to varying procedural demands.

Optimal Design for Clinical Environments

Crafted with a sturdy metal body and polycarbonate panel, this rectangular device is lightweight and compact. Its silent forced air cooling and low noise operation (<30 dB) maintain a quiet working environment, while advanced protections ensure durability and safety in everyday use.

FAQs of PWM Controlled LED Endoscopy Light Source:

Q: How does the PWM controlled LED light source benefit endoscopic procedures?

A: This device allows precise, stepless brightness adjustment from 0-100% using PWM technology, ensuring optimal illumination without flicker. Its high luminous flux and stable output provide detailed visualization during examinations and surgeries, improving diagnostic accuracy and procedural safety.

Q: What is the process for adjusting the light intensity?

A: Users can adjust the brightness either via an ergonomic PWM slider or digitally through the LED display panel. The stepless control allows real-time changes to light intensity, supporting a variety of endoscopic applications and improving adaptability during use.

Q: When should the light source be utilized in medical settings?

A: The light source is best employed during all forms of endoscopic examinations and surgical interventions that require high-intensity, stable illumination. Its instant-on feature ensures immediate readiness and efficiency, which is critical in emergency or routine procedures.

Q: Where can this light source be used?

A: It is intended for use in hospitals, clinics, and surgical centers across India and globally. Its universal compatibility means it can be integrated seamlessly with all standard rigid and flexible endoscopes, regardless of brand.

Q: What protection features are included to ensure device safety?

A: The unit incorporates overload, over-voltage, and over-temperature protections, safeguarding both the device and the endoscopic equipment from electrical or thermal risks during operation.

Q: How is heat managed during prolonged use?

A: The light source uses a silent forced air cooling mechanism that efficiently dissipates heat. With low heat emission from the LED and quiet operation (<30 dB), it maintains device performance and user comfort even during extended procedures.
